제품 상세 정보:
|
| 제품명: | 화웨이 네트워크 스위치 | 부품 번호: | S5735-l48t4xe-a-v2 |
|---|---|---|---|
| 지불: | TT / 페이팔 | 선적: | DHL |
| 상태: | 새로운 | 리드타임: | 2~3일 |
| 보증: | 1년 | 키워드: | S5735-l48t4xe-a-v2 |
| 강조하다: | Huawei S5735-L network switch,48-port GE RJ45 switch,4x10GE SFP+ Huawei switch |
||
The Huawei S5735-L48T4XE-A-V2 is a cutting-edge layer 3 Ethernet switch designed for enterprise networks. Engineered to support high-speed data, voice, and video communications, it integrates security, reliability, and energy-saving features. This versatile switch is suitable for diverse network deployment scenarios, including access and aggregation layers.
| Brand | Huawei |
| Model | S5735-L48T4XE-A-V2 |
| Form Factor | Fixed Port |
| Ports | 48 x 10/100/1000Base-T, 4 x 10GE SFP+ |
| Power Over Ethernet | Supported |
| SFP Transceiver Module | Model XYZ |
| External Power Supply | Model ABC |
| Rack Mount Kit | Model 123 |
| Model | Differences |
| S5735-L24T4X-A | Fewer ports, no PoE support |
| S5720-32X-EI-AC | Lacks 10GE SFP+ ports, different power specifications |
| S5730-H48T4XC | Higher port density, adds 40GE QSFP+ uplinks |
S5735-L48T4XE-A-V2 Specifications |
|
| Product Name | S5735-L48T4XE-A-V2 |
| Brand | Huawei |
| Device Type | Managed Switch |
| Fixed Ports | 48 x 10/100/1000Base-T Ethernet ports, 4 x 10GE SFP+ |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 130.95 Mpps |
| Flash Memory | 512 MB |
| DRAM | 1 GB |
| Power Supply | Dual, hot-swappable power supplies |
| Power Consumption | < 43.6W |
| Input Voltage | AC: 100V-240V, DC: -48V/-60V |
| Dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm |
| Operating Temperature | -5°C to 50°C |
| Operating Humidity | 5% to 95% (non-condensing) |
| MAC Address Table | 32K |
| Jumbo Frame | Up to 9216 Bytes |
| Quality of Service (QoS) | Supports priority queues, provides queue scheduling, congestion avoidance |
| Management Features | Web-based management, SNMP v1/v2c/v3, CLI (Console/Telnet/SSH), RMON |
| Security Features | AAA, Secure Shell (SSH), Secure Sockets Layer (SSL), IEEE 802.1X, IP/Port/MAC binding, Port security |
| Networking Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae |
| Layer Services | Layer 2 switching, Layer 3 routing |
| VLAN Features | Supports up to 4K VLANs simultaneously (out of 4096 VLAN IDs) |
| Warranty | Limited Lifetime |
