제품 상세 정보:
|
| 제품명: | 액세스 포인트 | 부품 번호: | AirEngine5762C-10-V2 |
|---|---|---|---|
| 지불: | TT | 선적: | DHL |
| 상태: | 새로운 | 리드타임: | 2~3일 |
| 보증: | 1년 | 키워드: | AirEngine5762C-10-V2 |
| 강조하다: | Huawei AirEngine Wi-Fi 6 access point,dual-band indoor wireless AP,high-speed 2.975Gbps access point |
||
| Parameter | Details |
|---|---|
| Wi-Fi Standard | Wi-Fi 6 (IEEE 802.11ax) |
| Frequency Band | 2.4 GHz & 5 GHz Dual-Band |
| Max Rate | 2.975 Gbps (575 Mbps + 2.4 Gbps) |
| Antenna | Built-in Smart Antennas |
| Interface | 1 x GE (RJ45) Port |
| Power Supply | PoE (802.3af) / DC 12V |
| Dimensions | Φ180 mm × 35 mm |
| Weight | 0.46 kg |
| Category | Specification |
|---|---|
| General | |
| Product Model | AirEngine 5762C-10-V2 |
| Product Type | Indoor Wireless Access Point (AP) |
| Wireless Features | |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6). |
| Frequency Band | 2.4 GHz (2x2 MIMO) & 5 GHz (2x2 MIMO). |
| Max. Rate | 2.4 GHz: 575 Mbps; 5 GHz: 2.4 Gbps; Total: 2.975 Gbps. |
| Channel Bandwidth | 20 MHz, 40 MHz, 80 MHz, 160 MHz. |
| Modulation Technology | 1024-QAM. |
| Antenna Type | Built-in dual-band co-planar smart antennas. |
| Antenna Gain | 2.4 GHz: 4 dBi; 5 GHz: 5 dBi |
| Interfaces | |
| Wired Interface | 1 x 10/100/1000BASE-T Ethernet (RJ45) |
| Power Input | PoE: 802.3af; DC: 12 V ± 10% |
| LED Indicator | System status (Power, Run, Alarm) |
| Physical & Environment | |
| Dimensions (D×H) | Φ180 mm × 35 mm |
| Weight | 0.46 kg |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Operating Humidity | 5% – 95% (non-condensing) |
| Power & Performance | |
| Max. Power Consumption | 11.2 W |
| Working Modes | Fit AP, Fat AP, Cloud-Managed AP. |
