Cisco C9500-24Y4C-E Switch | Catalyst 9500 24-Port 25G Enterprise Core Switch

Cisco C9500-24Y4C-E Switch | Catalyst 9500 24-Port 25G Enterprise Core Switch
Cisco C9500-24Y4C-E Switch | Catalyst 9500 24-Port 25G Enterprise Core Switch Cisco C9500-24Y4C-E Switch | Catalyst 9500 24-Port 25G Enterprise Core Switch Cisco C9500-24Y4C-E Switch | Catalyst 9500 24-Port 25G Enterprise Core Switch

큰 이미지 :  Cisco C9500-24Y4C-E Switch | Catalyst 9500 24-Port 25G Enterprise Core Switch

제품 상세 정보:
원래 장소: 중국
브랜드 이름: CISCO
인증: CE
모델 번호: C9500-24Y4C-E

Cisco C9500-24Y4C-E Switch | Catalyst 9500 24-Port 25G Enterprise Core Switch

설명
제품명: 시스코 이서네트 스위치 부품 번호: C9500-24Y4C-E
선적: DHL/페이팔 지불: TT / 페이팔
상태: 새로운 보증: 1년
리드타임: 1~3일 핵심 단어: C9500-24Y4C-E

Overview

The Cisco Catalyst C9500-24Y4C-E is a next-generation enterprise core and aggregation switch designed for high-performance campus and data center environments. Equipped with 24 x 1/10/25G SFP28 ports and 4 x 40/100G QSFP28 uplinks, this Cisco Catalyst 9500 switch delivers outstanding scalability, ultra-low latency, and advanced Layer 3 functionality for modern enterprise networks.

Built on Cisco’s powerful x86 architecture, the C9500-24Y4C-E supports automation, SD-Access, StackWise Virtual technology, and advanced security capabilities, making it an ideal solution for enterprise core, aggregation, and high-density fiber deployments.




Key Features of Cisco C9500-24Y4C-E
24 High-Speed 1/10/25G SFP28 Ports

Supports flexible enterprise connectivity with high-density 25G access for servers, aggregation, and campus backbone deployments.

4 x 40G/100G QSFP28 Uplinks

Provides ultra-fast uplink connectivity for core networks, data centers, and cloud-scale applications.

Enterprise-Class Performance
  • Switching capacity up to 2 Tbps
  • Forwarding rate up to 1 Bpps
  • Up to 82,000 MAC addresses
  • Support for jumbo frames up to 9216 bytes
Advanced Layer 3 Routing

Supports:

  • OSPF
  • EIGRP
  • BGP
  • MPLS
  • VRF
  • Policy-based routing
  • Multicast VPN
StackWise Virtual Technology

Enables simplified network virtualization and redundancy without traditional chassis-based infrastructure.

Enhanced Security

Includes:

  • ACL security policies
  • DHCP Snooping
  • MAC filtering
  • Secure segmentation
  • SD-Access support



Cisco C9500-24Y4C-E Specifications
Specification Details
Model C9500-24Y4C-E
Product Series Cisco Catalyst 9500
Ports 24 x 1/10/25G SFP28
Uplink Ports 4 x 40/100G QSFP28
Switching Capacity Up to 2 Tbps
Forwarding Rate Up to 1 Bpps
DRAM 16 GB
Flash Memory 16 GB
VLAN IDs 4000
Form Factor 1RU
License Network Essentials
Deployment Core / Aggregation / Data Center
StackWise Virtual Supported



Why Choose Cisco C9500-24Y4C-E?
Designed for Enterprise Core Networks

The C9500-24Y4C-E is purpose-built for enterprise campus core and aggregation layers, offering exceptional scalability and high availability.

Future-Proof 25G & 100G Architecture

25G server connectivity and 100G uplinks ensure your infrastructure is ready for AI workloads, cloud applications, virtualization, and high-density traffic.

Reliable Cisco Ecosystem

Cisco Catalyst 9500 Series switches are widely trusted by enterprises worldwide for their stability, security, and long lifecycle support.




FAQ
What is the difference between C9500-24Y4C-E and C9500-24Y4C-A?
Feature C9500-24Y4C-E C9500-24Y4C-A
License Network Essentials Network Advantage
Basic Layer 3 Routing Yes Yes
Advanced SD-Access Features Limited Full
MPLS Support Limited Advanced
Enterprise Core Deployment Yes Yes
Advanced Automation Basic Enhanced

The “-E” version is suitable for most enterprise core and aggregation environments, while the “-A” model is recommended for advanced SD-Access and automation-heavy deployments.


Is the Cisco C9500-24Y4C-E suitable for data centers?

Yes. With 25G SFP28 ports and 100G uplinks, the C9500-24Y4C-E is highly suitable for:

  • Enterprise data centers
  • High-density server aggregation
  • Cloud infrastructure
  • Campus core environments

Does C9500-24Y4C-E support third-party optics?

The switch is optimized for Cisco-compatible optics. Some third-party DACs or transceivers may trigger compatibility warnings or require additional configuration. Real-world discussions from network engineers show compatibility varies depending on firmware and optics vendor.


Can the 100G uplink ports be used for 10G connections?

Yes. By using compatible QSFP-to-SFP adapters, the uplink ports can support lower-speed connections such as 10G in certain deployment scenarios.


Does the switch support StackWise Virtual?

Yes. Cisco StackWise Virtual technology allows two Catalyst 9500 switches to operate as one logical switch for improved redundancy and simplified management.




Typical Deployment Scenarios
  • Enterprise campus core
  • High-speed aggregation layer
  • Data center spine/aggregation
  • Large enterprise fiber access
  • Cloud-ready enterprise networks
  • Financial institutions
  • Education networks
  • Healthcare infrastructure



After-Sales Service & Warranty
Professional Technical Support

We provide:

  • Product consultation
  • Compatibility guidance
  • Configuration assistance
  • Firmware support
  • Deployment recommendations
Fast Global Shipping
  • Worldwide delivery
  • Secure packaging
  • Real-time logistics tracking
Quality Assurance
  • Genuine Cisco hardware
  • Fully tested before shipment
  • Warranty support available



Recommended Related Models
Model Ports Best For
C9500-16X-E 16 x 10G Medium enterprise core
C9500-24X-E 24 x 10G High-density aggregation
C9500-48Y4C-E 48 x 25G Large-scale campus core
C9300X-24Y-E 24 x 25G Enterprise access layer
