제품 상세 정보:
|
| 제품명: | 광트랜시버 모듈 | 폼 팩터: | QSFP-DD |
|---|---|---|---|
| 데이터 속도: | 800Gbps | 파장: | CWDM8 1271nm 1291nm 1311nm 1331nm 1351nm 1371nm 1391nm 1411nm |
| 광 인터페이스: | MPO‑12 APC 커넥터 | 전원공급장치: | 단일 3.3v |
| 핫스왑 가능: | 예 | 레이저 클래스: | 1 |
This enterprise-grade 800G QSFP‑DD LR8 optical transceiver is optimized for 10km single-mode fiber (SMF) links. It leverages 8-channel CWDM8 wavelengths and PAM4 modulation to deliver high bandwidth with efficient fiber usage. Equipped with digital optical monitoring (DOM) and hot-swappable design, it ensures reliable operation and easy maintenance.
| Parameter Name | Parameter Value |
|---|---|
| Product Type | 800G QSFP‑DD LR8 Optical Transceiver |
| Form Factor | QSFP‑DD 800 MSA Compliant |
| Data Rate | 800Gbps (8×106.25Gbps PAM4) |
| Wavelength | CWDM8 1271nm 1291nm 1311nm 1331nm 1351nm 1371nm 1391nm 1411nm |
| Transmission Distance | 10km Over SMF (OS2) |
| Optical Interface | MPO‑12 APC Connector |
| Digital Monitoring | DOM (Digital Optical Monitoring) |
| Power Supply | Single 3.3V |
| Hot‑Swappable | Yes |
| Standards Compliance | IEEE 802.3ck IEEE 802.3df CMIS 5.0 QSFP‑DD MSA |
| Typical Power Consumption | ≤16W |
| Operating Temperature | 0°C To 70°C |
| Storage Temperature | -40°C To 85°C |
| Laser Class | 1 |
| RoHS Compliance | Yes |
This high-performance 800G optical transceiver provides 800Gbps throughput via 8×106.25G PAM4 electrical interfaces. It adopts CWDM8 wavelength division technology to maximize fiber utilization, reducing deployment costs. With 10km SMF transmission capability, it is ideal for data center interconnection and metro area network (MAN) applications.
Data center core/aggregation switch interconnection, Metro area network (MAN) backbone interconnection, Data center intra-site and inter-site communication, High-speed interconnection of AI computing clusters, Telecom central office interconnection, Cloud service provider network expansion & upgrade.
