제품 상세 정보:
|
| 모델: | Huawei CloudEngine 8855-32CQ4BQ -B | 포트: | 32 × 100 GE QSFP28, 4 × 200 GE QSFP56 |
|---|---|---|---|
| 스위칭 용량: | 8 Tbps | 전달 성능: | 1,200 MPPS |
| 직물 및 가상화: | VXLAN/BGP-EVPN, M-LAG | QOS 및 정체 제어: | PFC, WRED, ECN, AI-ECN |
| 유지 보수 기능: | 원격 측정, ZTP, 하드웨어 BFD, 포트 표시기 | 전원 공급 장치: | 2 × 1,200 W AC (전면 섭취) |
| 강조하다: | Huawei CloudEngine 32-port 100GE switch,Huawei 8Tbps network switch,Huawei 200GE high-speed switch |
||
| Parameter | Specification |
|---|---|
| Model | Huawei CloudEngine 8855-32CQ4BQ-B |
| Ports | 32 × 100 GE QSFP28, 4 × 200 GE QSFP56 |
| Switching Capacity | 8 Tbps |
| Forwarding Performance | 1,200 Mpps |
| Fabric & Virtualization | VXLAN/BGP-EVPN, M-LAG |
| QoS & Congestion Control | PFC, WRED, ECN, AI-ECN |
| Maintenance Features | Telemetry, ZTP, hardware BFD, port indicators |
| Power Supplies | 2 × 1,200 W AC (front intake) |
| Cooling | 5 × fan trays, front intake |
| Power Consumption | 378 W typical, 541 W maximum |
| Dimensions (H×W×D) | 43.6 × 442 × 420 mm |
| Weight (full config) | 8.31 kg |
| Operating Temperature | 0-40 °C |
| Airflow Direction | Front-port intake |
| Certifications | EMC, RoHS, FCC, UL standards |
